offers a complete set of conductors covering a broad application spectrum.

Designed to deliver the best reliability/performance vs. system level cost, these materials enable more cost-effective manufacturing processes, including fine line printing, 30 or 60 minute firing profiles, co-fireability and unprecedented field reliability.

The conductors allow several different interconnect strategies, ranging from 25-micron gold wirebond to heavy gauge aluminum wirebond, wedge bond, ribbon bond, ball grid array (BGA), flip chips, and more.

Additional benefits include low noise characteristics (rated up to five times better than those of conventional systems), improved post-laser trim stability (improved by a factor of three), and outstanding durability at high temperatures.

 conductive/resistive hydro-active ink

Emerging PE-Kapton? Inks

Emerging PE-Kapton? inks is turning the heat up with this ink family that provides extreme Versality and Thermal Performance for applications where extremes of heat and vibration are the norm. Designers have relied on Kapton film because of its ability to maintain its unique combination of mechanical and electrical properties under the harshest of conditions. Now DuPont brings these capabilities to a line of conductive and insulating electronic inks.

DuPont offers a broad selection of hybrid circuit materials to meet the requirements of different substrates, operating environments, temperatures, and metallizations. Conductor materials from DuPont are available in a wide variety of traditional thick film compositions, including silver, gold, platinum and their alloys.

Self limiting Heaters

New Enabling Positive Temperature Coefficient (PTC) Ink Technology

Self-regulating/Self-limiting due to a large resistance increase with increasing temperature

Improved stability

No pre-conditioning needed

Wide range of compatible adhesive

Silver/Platinium Conductors

DuPont Ag/Pt conductors offer high solder leaching resistance and good soldering performances.

Gold based conductors

Gold conductors are used for high reliability applications owing to their low resisitivity, resistance to metal migration even in harse environments and non oxidation and corrodation properties.

Silver/Palladium Conductors

DuPont Silver Palladium conductors limit the silver migration in harsh envrionment and improve solderability.

Platinium conductors

DuPont Platinium conductors are suitable to operate at elevated temperatures and can be used as electrodes for sensors applications.

Additional products and information

Related products

ResistorsDielectric & EncapsulantLTCC AlN paste systemAlu, Glass & Steel paste systems

More from Hybrid circuits

Bonding wires

More from DuPont conductive paste

MTS & RFIDIntexar? Strechable Electronics

In-Mold (IME)

杜邦提供了一套完整的導體，涵蓋了廣泛的應用范圍。
這些材料旨在提供最佳的可靠性/性能與系統級成本，可實現更具成本效益的制造工藝，包括細線印刷、30 或 60 分鐘燒制曲線、共燒性和前所未有的現場可靠性。
導體允許多種不同的互連策略，從 25 微米金線鍵合到大規格鋁線鍵合、楔形鍵合、帶狀鍵合、球柵陣列 (BGA)、倒裝芯片等。
其他好處包括低噪音特性（比傳統系統好五倍）、改進的激光后微調穩定性（提高了三倍）以及在高溫下的出色耐用性。
導電/電阻水活性油墨
新興的 PE-Kapton? 油墨
新興的 PE-Kapton? 墨水正在通過這個墨水系列來提高熱度，該系列為極端高溫和振動是常態的應用提供了極端的通用性和熱性能。設計師一直依賴 Kapton 薄膜，因?yàn)樗軌蛟谧類毫拥臈l件下保持其獨特的機械和電氣性能組合?，F(xiàn)在，杜邦將這些功能引入了一系列導電和絕緣電子墨水。
杜邦提供廣泛的混合電路材料選擇，以滿足不同基板、操作環境、溫度和金屬化的要求。杜邦的導體材料有多種傳統的厚膜成分，包括銀、金、鉑及其合金。
自限加熱器
新的啟用正溫度系數 (PTC) 墨水技術
由于電阻隨溫度升高而增加的大的自調節/自限制
提高穩定性
無需預處理
廣泛的兼容粘合劑
銀/鉑導體
杜邦 Ag/Pt 導體提供高抗焊料浸出性和良好的焊接性能。
金基導體
金導體由于其低電阻率、即使在惡劣環境中也能抵抗金屬遷移以及非氧化和腐蝕特性而用于高可靠性應用。
銀/鈀導體
杜邦銀鈀導體可限制惡劣環境中的銀遷移并提高可焊性。
鉑金導體
DuPont Platinium 導體適合在高溫下工作，并可用作傳感器應用的電極。

以上材料如有需求致電13922125860
